Description
|
Main |
|
|
Range |
Miluz |
|
Product or component type |
USB charger |
|
Device application |
USB charger |
|
Fixing mode |
By claws |
|
By screws |
|
|
Integrated connection type |
2 USB port 5 V DC, maximum load current: 2.4 A |
|
Operating system |
Mac iOS |
|
Android |
|
|
Harmony |
|
|
Complementary |
|
|
Device mounting |
Flush |
|
device presentation |
Insert |
|
Colour tint |
White |
|
Surface finish |
Glossy |
|
Number of modules |
1 module |
|
Type of packing |
Plastic bag |
|
Quantity per set |
1 |
|
ambient air temperature for operation |
0…40 °C |
|
Ambient air temperature for storage |
-5…60 °C |
|
Relative humidity |
10…90 % |
|
Connector type |
USB |
|
[Ue] rated operational voltage |
110/240 V AC +/- 10 % at 50/60 Hz |
|
Power consumption in W |
0.1 W |
|
Nominal output power |
12 W |
|
Input power |
14.5 W |
|
Service life in hours |
30000 h |
|
maximum load current with 2 outputs used simultaneously |
2.4 A |
|
Material |
PC (UL94 V-0) |
|
Protection type |
Overload of output voltage |
|
Thermal protection |
|
|
Current protection |
|
|
Wire stripping length |
103 mm |
|
Product compatibility |
Mobile/tablet |
|
height |
44.75 mm |
|
Width |
22.3 mm |
|
Depth |
39.9 mm |
|
Embedding depth |
31.2 mm |
|
Number of terminals |
2 wire |
|
Environment |
|
|
Directives |
2006/95/EC - low voltage directive |
|
product certifications |
low voltage directive 2006/95/EC |
|
Standards |
IEC/EN 62386-101 |
|
IK degree of protection |
IK04 |
|
IP degree of protection |
IP20 |
|
Electrical insulation class |
Double insulation |
