Schneider circuit breaker 25 kA at 415 V AC, 32 A rating thermal magnetic TM-D trip unit, 3P 3d - LV510302

Product or component type

Circuit breaker

Device application

Distribution

Poles description

3P

Protected poles description

3D

Earth leakage protection (Vigi add on)

Without

[In] rated current

32 A at 40 °C

network type

AC

Utilisation category

Category A

[Icu] Breaking capacity

40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2

25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2

20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2

Trip unit name

TM-D

Trip unit technology

Thermal-magnetic

Trip unit rating

32 A at 40 °C

Protection type

Overload protection (thermal)

Short-circuit protection (magnetic)

[Uimp] rated impulse withstand voltage

8 kV conforming to EN/IEC 60947-2

Network frequency

50/60 Hz

Breaking capacity code

B

[Ics] rated service breaking capacity

15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2

25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2

40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2

Mechanical durability

30000 cycles

Electrical durability

12000 cycles 415 V In conforming to IEC 60947-2

Control type

Toggle

Thermal protection adjustment range

22.4…32 A

Long time pick-up adjustment type Ir

Adjustable

Long time pick-up adjustment range

0.7…1 x In

Long time delay adjustment type

Fixed

Instantaneous pick-up adjustment type Ii

Fixed

Instantaneous pick-up adjustment range

400 A

Contact position indicator

Yes

Mounting support

Backplate

Mounting mode

Fixed

Upside connection

Front

Downside connection

Front

Connections – terminals

Screw connection

Connection pitch

35 mm

Compatibility code

CVS100

Width * Depth * Height

105 *86 *161 mm

Product weight

1.5 kg
