Description
| Brand | Mean Well | ||||||||
| Model | LRS-35-24 | LRS-50-24 | LRS-75-24 | LRS-100-24 | LRS-150-24 | LRS-200-24 | LRS-350-24 | LRS-450-24 | LRS-600-24 |
| TECHNOLOGY | AC/DC | ||||||||
| INPUT VOLTAGE (VAC) | 100~240 | ||||||||
| OUTPUT VOLTAGE (VDC) | 24 | ||||||||
| OUTPUT CURRENT (A) | 1.5A | 2.2A | 3.2A | 4.5A | 6.5A | 8.8A | 14.6A | 18.8 A | 25A |
| OUTPUT POWER (W) | 35 | 50 | 75 | 100 | 150 | 200 | 350 | 450 | 600 |
| SHAPE | Enclosed | ||||||||
| PRODUCT DIMENSION (LXWXH) (MM) | 99x82x30 | 99x82x30 | 99x97x30 | 129x97x30 | 159x97x30 | 215x115x30 | 215x115x30 | 225*124*35 | 225x124x41 |
| PRODUCT WEIGHT (KG) | 0.22 | 0.22 | 0.25 | 0.33 | 0.42 | 0.62 | 0.76 | 0.85 | 0.95 |
